Gooseneck
Trailers

Just click
image for a larger View
Goose Neck Trailers, , gooseneck trailer sales, goose neck trailer
manufacture.
Pricing & Specifications / Options
| Add
On Options |
|
|
Add
On Options |
|
| Extra
Brake Axles |
$100.00 |
Self
Cleaning Dove |
$300.00 |
| Tri
- Axle |
$650.00 |
Break-Away
Kits |
$40.00 |
| 20"
x 20" x 46" Aluminum Tool Box |
$300.00 |
Pop
Up Dove |
$300.00 |
| Gooseneck
Trailers GVW
14,000 lb |
- .10" I-Beam @ 15 lb.
frame & neck
- Cross members 3"
channel on 2 ft. centers
- 8" channel cross
members in frame
- 3" x 5" x
1/4" angle outside rail
- Treated floor
- Stake pockets
- Rub rail
|
- Adjustable 2-5/16"
gooseneck hitch
- Chain box in front
- Extra heavy duty 3"
channel chain up ramps
- 10,000 lb. drop leg jack
- 16" 10 ply Tires
- Flat or Dove Tail
|
|
| Over all
Width - Length Ft. |
Axles |
# of Brake axles |
|
| 8 x 16 + 4 |
(2) 7000 lb. |
3500 lb. (2) |
$3,955 |
| 8 x 20 + 5 |
(2) 7000 lb. |
4000 lb. (2) |
$4,240 |
| 8 x 25 + 5 |
(2) 7000 lb. |
4500 lb. (2) |
$4,655 |
| 8 x 30 + 5 |
(2) 7000 lb. |
5000 lb. (2) |
$5,205 |
|
| Gooseneck
Trailers GVW
18,000 lb |
- 12" I-Beam @ 19 lb.
frame & neck
- Cross members 3"
channel on 18" centers
- 10" channel cross
members in frame
- 6" Channel outside frame
- Treated floor
- Stake pockets
- Rub rail
|
- Check Plate Over Tires
- Chain box in front
- 4"
channel chain up ramps
- 10,000 lb. drop leg jack
- 16" 10 ply Radial Tires
- New Bud Wheels
- Available in Flat or Dove
Tail
|
|
| Over all
Width - Length Ft. |
Axles |
# of Brake axles |
|
| 8 x 16 + 4 |
(2) 9000 lb. |
4800 lb. (2) |
$5,840 |
| 8 x 20 + 5 |
(2) 9000 lb. |
5250 lb. (2) |
$6,125 |
| 8 x 25 + 5 |
(2) 9000 lb. |
5600 lb. (2) |
$6,595 |
| 8 x 30 + 5 |
(2) 9000 lb. |
5850 lb. (2) |
$7,015 |
|
| Gooseneck
Trailers
GVW 20,000
lb |
- 12" I-Beam @ 19 lb.
frame & neck
- Cross members 3"
channel on 18" centers
- 10" channel cross
members in frame
- 6" Channel outside frame
- Treated floor
- Stake pockets
- Rub rail
|
- Check Plate Over Tires
- Chain box in front
- 4"
channel chain up ramps
- 10,000 lb. drop leg jack
- 16" 10 ply Radial Tires
- New Bud Wheels
- Available in Flat or Dove
Tail
|
|
| Over all
Width - Length Ft. |
Axles |
# of Brake axles |
|
| 8 x 16 + 4 |
(2) 10k |
2 |
$5,995 |
| 8 x 20 + 5 |
(2) 10k |
2 |
$6,285 |
| 8 x 25 + 5 |
(2) 10k |
2 |
$6,830 |
| 8 x 30 + 5 |
(2) 10k |
2 |
$7,275 |
| 8 x 35 + 5 |
(2) 10k |
2 |
$7,930 |
| 8 x 40 + 5 |
(2) 10k |
2 |
$8,530 |
|
| Gooseneck
Trailers GVW
24,000 lb |
- 12" I-Beam @ 19 lb.
frame & neck
- Cross members 3"
channel on 18" centers
- 10" channel cross
members in frame
- 6" Channel outside frame
- Treated floor
- Stake pockets
- Rub rail
|
- Check Plate Over Tires
- Chain box in front
- 4"
channel chain up ramps
- 10,000 lb. drop leg jack
- 16" 14 ply Tires
- New Bud Wheels
- Available in Flat or Dove
Tail
|
|
| Over all
Width - Length Ft. |
Axles |
# of Brake axles |
|
| 8 x 16 + 4 |
(2) Heavy Duty 10k. |
2 |
$7,205 |
| 8 x 20 + 5 |
(2) Heavy Duty 10k. |
2 |
$7,650 |
| 8 x 25 + 5 |
(2) Heavy Duty 10k. |
2 |
$8,065 |
| 8 x 30 + 5 |
(2) Heavy Duty 10k. |
2 |
$8,380 |
| 8 x 35 + 5 |
(2) Heavy Duty 10k. |
2 |
$8,710 |
| 8 x 40 + 5 |
(2) Heavy Duty 10k. |
2 |
$ 9,030 |
|
